Multiquip MRH601DS – Double Drum Vibratory Roller
Features:
- Hydraulic drive system provides smooth machine operation
- Kubota liquid cooled engine with electric start provides long service life
- Automatic shut-off button located at the top of the handle keeps the operator safe when actuated
- Hourmeter measures runtime
- Electromagnetic clutch for fast and smooth engagement of vibrator function
- Water tank with 7.9 gallon capacity for long runtime on asphalt applications
- Fold-up guide handle for easy transport and storage
- Horn and headlight switch for job-site safety
- Parking break and stoppers for job-site placement stability
Unit Specifications
- Compaction Force 2428 lb 10.8 kN
- Frequency 3,300 VPM 55 Hz
- Travel Speed 0-1.86 mph 0-3 kph
- Water Tank Capacity 7.9 gal 29.9 L
- Drum Specifications
- Front Drum Width 25.6 in 650 mm
- Rear Drum Width 25.6 in 650 mm
Dimensions & Weights
- Overall Length 89.2 in 2266 mm
- Overall Width 27.2 in 691 mm
- Overall Height 47 in 1194 mm
- Operating Weight 1248 lb 566 kg
